Based in Chennai, India, Vinit Stainless is a well-known producer and supplier of premium stainless steel fittings. Vinit Stainless has established a solid reputation in the metal industry by prioritising customer satisfaction, precision engineering, and durability. The sturdy and corrosion-resistant stainless steel tee is one of the company’s many stainless steel products. Vinit Stainless, which serves a variety of industries like construction, oil and gas, and chemical processing, guarantees that every product satisfies global quality standards. They are the go-to option for stainless steel solutions in India and around the world because of their dedication to innovation and quality.
Vinit Stainless’s stainless steel tees are typically made of grades like SS304, SS316, and SS316L, which provide exceptional strength and resistance to corrosion. Chromium (18–20%), nickel (8–10.5%), and molybdenum (2–3% in 316) are among the constituents. These tees have outstanding elongation (up to 40%), good yield strength (205 MPa), and high tensile strength (515–620 MPa). They are appropriate for high-temperature and high-pressure applications due to their mechanical characteristics. Since stainless steel tees are so tough and weldable, they hold up well in harsh environments, guaranteeing dependable operation in vital fluid distribution and piping systems.
| Grades | 201, 202, 304, 304L, 304H, 309S, 309H, 310S, 310H, 316, 316TI, 316H, 316L, 316LN, 317, 317L, 321, 321H, 347, 347H, 904L |
| Type | Seamless / Welded / Fabricated |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Size | ½”NB to 48″NB in |
| Schedule | Sch 10s, 40s, 80s, 160s, XXS. |
| Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43. |
| SS | 304 | 304N | 304LN |
|---|---|---|---|
| Ni | 8 – 11 | 8 – 11 | 8 – 11 |
| Fe | Balance | ||
| Cr | 18 – 20 | 18 – 20 | 18 – 20 |
| C | 0.08 max | 0.08 max | 0.035 max |
| Si | 0.75 max | 0.75 max | 0.75 max |
| Mn | 2 max | 2 max | 2 max |
| P | 0.040 max | 0.040 max | 0.040 max |
| S | 0.030 max | 0.030 max | 0.030 max |
| N | 0.10 – 0.16 | 0.10 – 0.16 | |
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
Contact us to get a quick quote for your requirement.
We ensure that every Stainless Steel Tee Fitting undergoes rigorous testing before leaving our premises, maintaining the highest quality standards at all times. Hardness Testing, Chemical Analysis (Spectro Analysis), Positive Material Identification (PMI Testing), Flattening Test, Micro and Macro Testing, Pitting Resistance Test, Flaring Test and Intergranular Corrosion (IGC) Testing are just some of the tests performed on Stainless Steel Tee Fittings before shipping.
Yes, stainless steel tees are fully recyclable. They can be melted down and reused without losing their properties, making them an environmentally friendly and sustainable material choice.
Common grades of stainless steel used in tee fittings manufacturing include 304, 304L, 316, 316L, and 321. These grades offer excellent corrosion resistance, durability, and suitability for various applications.
Yes, stainless steel tee fittings are ideal for hygienic and sanitary applications due to their corrosion resistance, smooth surfaces, and ease of cleaning, meeting strict industry standards.
Key considerations for selecting stainless steel tee fittings include material grade, corrosion resistance, pressure and temperature requirements, compatibility with media, application standards, and cost-effectiveness for long-term use.
In piping systems, stainless steel tees are crucial parts for dividing or combining fluid flow. These fittings, which are widely used in sectors like water treatment, petrochemicals, food processing, pharmaceuticals, and oil and gas, guarantee connections that are impervious to corrosion and leaks. They are perfect for high-demand systems because of their strength and resistance to high pressures and temperatures. Stainless steel tees offer enduring durability and hygienic conditions in both commercial and residential plumbing. They are also utilised in marine applications, fire safety networks, and HVAC systems where dependability and corrosion resistance are essential for preserving system safety and efficiency.
